Description

10 Gbps network performance (Cat6A TIA-568.2-D) for high-speed Ethernet applications.
Shielded design (STP) with gold plated contacts to reduce interference and improve signal integrity.
Works with solid cables 22-26 AWG / stranded 22-27 AWG — versatile cable compatibility.
Rated for PoE / PoE+ / PoE++ (IEEE 802.3bt Type 3/4) allowing up to ~90W power delivery over Ethernet.
Dielectric withstand voltage: 1000V DC; insulation resistance ≥ 500 MΩ; contact resistance ≤ 20 mΩ — ensures reliability.
Rugged housing (zinc alloy) + durable mating cycles (~750 insert/removal cycles).
Wide operating temperature: −40 °C to +85 °C — usable in harsh/industrial environments.
IP20 protection; tool-assisted termination (parallel jaw pliers) for speedy field installation.
Backward compatible with lower categories (Cat6, Cat5e) — works with existing network setups.
Compact size; supports cable diameters 6-9 mm, re-terminable up to 5 times.
