Description

Connector Type: SC connector at both ends (SC-SC), simplex design (single fibre).
Optical Fibre Type: Single-Mode (≈ 9 µm core, typical standard G.652D / G.657A/B) for long-distance, low attenuation applications.
Length & Jacket: 1 metre cable, with yellow jacket (as per single-mode convention). PVC jacketing standard; LSZH available on request.
High Precision Termination: Ceramic ferrule connectors; good concentricity and mechanical / optical end-face geometry (apex offset, radius of curvature etc.).
Optical Performance: Low insertion loss (typical ≤ 0.2 dB, maximum ≤ 0.3 dB); good return loss (UPC/PC versions).
Mechanical & Environmental Specs: Durable for frequent mating cycles; stable performance over a wide temperature range (~ -40 °C to +85 °C).
Standard Compliance: Meets standard fibre optic pigtail specifications from SM fibre; end-face polishing; inspection of end-face finish.
Applications: Ideal for splicing, patch panels, fibre distribution frames, telecommunication racks, data centres, LAN backbones where Single-Mode links are required.
