Description

Hardware & Performance
Processor & Memory: 400 MHz CPU, 128 MB DDR3 RAM, 128 MB NAND flash
Power & Form: Input 220 V AC (12 V, 1 A adapter); ≤ 9 W consumption; dimensions ≈ 185 × 120 × 32 mm; weight ~280 g
Environmental: Operating: –5°C to +55 °C, humidity 10–90%; Storage: –30 °C to +60 °C, 10–90% non-condensing
Connectivity & Interfaces
GPON/EPON: SC/PC single-mode optical port; up to 2.5 Gbps downstream / 1.25 Gbps upstream; Tx 1310 nm, Rx 1490 nm; sensitivity < –27 dBm, overload > –8 dBm (Class B+)
Ethernet Ports: 1× RJ-45 Gigabit (GE), 1× RJ-45 Fast Ethernet (FE), auto-negotiation/MDI-X
Voice: 1× POTS RJ-11 port with full VoIP support (G.711/G.729 etc.), echo cancellation & fax support
Wireless: Single-band Wi-Fi 802.11b/g/n @2.4 GHz, 300 Mbps (2T2R), with dual antennas & multi-SSID support
Software, Protocols & Network Features
L2/L3 Support: Bridge/Routing, VLAN (tag/trunk/QinQ), QoS (4 queues, SP/WRR, DSCP), IGMP/MLD Snooping & Proxy
L3 Functions: DHCP client/server, PPPoE, static routing, NAT, DMZ, virtual servers, firewall, ACL, MAC filtering, URL filtering, SIP support
VoIP Features: SIP-based voice, echo cancellation, multi-party conferencing, hotline, call waiting, line testing (GR-909 compliant), T.38 fax
Interfaces & Controls: Web-based UI, supports VLAN mode, L3 functions
